MIG Gun M400 Series

M400 is a newly designed, heavy-duty, durable, light weight MIG gun, equipped with a push-on nozzle as well as a comfortable ergonomic handle and Tweco®style torch head. This MIG gun possesses a unique capability of converting one termination style to other common styles such as Euro style, Lincoln®style, Tweco®style, or Miller®style by simply replacing them.

Available models :

MIG Torch, Tweco® style M400 TE , Euro termination, 15 Ft.
MIG Torch, Tweco® style M400 TE , Euro termination, 15 Ft.
SUITABLE FOR CANAWELD MACHINES

Part Number : CWGPGTW400-15E
MSRP : $298.00 CAD

Add to Cart

MIG Torch, Tweco® style M400 TT, Tweco® termination, 15 Ft.
MIG Torch, Tweco® style M400 TT, Tweco® termination, 15 Ft.


Part Number : CWGPGTW400-15T
MSRP : $298.00 CAD

Add to Cart

MIG Torch, Tweco® style M400 TL, Lincoln® termination, 15 Ft.
MIG Torch, Tweco® style M400 TL, Lincoln® termination, 15 Ft.


Part Number : CWGPGTW400-15L
MSRP : $298.00 CAD

Add to Cart

MIG Torch, Tweco® style M400, Miller® termination, 15 Ft.
MIG Torch, Tweco® style M400, Miller® termination, 15 Ft.


Part Number : CWGPGTW400-15M
MSRP : $298.00 CAD

Add to Cart

Description

  • Knuckle joint for improved balance and position-ability ensures that minor movements of the handle and neck be independent of the cable assembly .
  • Excellent heat, abrasion resistance, and flexibility of the cable .
  • Lighter than standard cable sets and capable to withstand over 1 million flexes in life testing .
  • Extremely durable contact tips manufactured from premium grade copper alloys .
  • Standard, durable, and high-performance options for tip adaptors, diffusers, and swan necks .
  • Improved insulation and minimized heat transfer to the handle .
  • Ergo design handle and comfortable handling .
  • Light gun handle, less tiredness of the welder because of the special gun design .
  • Air gap technology for cooler running handles and better heat transfer isolator from the swan neck .
  • Steel and combo liner for all kinds of wires such as steel (metalcore and flux-cored), stainless steel (metalcore and flux-cored), and Aluminum.
  • Unique sealing ring for effective sealing of impurities especially in the argon gas process .
  • Reduction in welder fatigue by improved handle design for welder’s comfort .
  • Push on nozzle system and easy nozzle stick-out adjustment .
  • High-quality trigger with a life expectancy of greater than 1 million cycles .
  • Technical specification
    Cooling Method: Air-Cooled
    Welding Output: 320A CO2 270A Mixed Gas at 60% Duty Cycle
    Recommended For: Solid wires: 0.030″ to 1/16″ (0.8 to 1.6 mm)
    Flux Cored wires: 0.030” to 1/16” (0.8 to 1.6 mm)
    Aluminum wires: 0.040” to 1/16” (1.0 to 1.6 mm)
    Recommended Gas Flow: For 1/2″ (12.8 mm) nozzle bore 22-27 CHF (11-13 l/min)
    For 5/8″ (16.0 mm) nozzle bore 30-35 CHF (14-17 l/min)
    For 3/4″ (19.0 mm) nozzle bore 30-40 CHF (14-19 l/min)
    Head and Nozzle style: Tweco® Style
    Central Connector type: Euro connector/ Lincoln® connector/ TWECO® connector/ Miller® Connector
    Gun Length: 15 ft. (4.5 meter).
