Superior True-View Welding Helmet Series

A good welding helmet is one of the most important pieces of P.P.E (personal protective equipment) a welder must wear. It protects the user eyes and skin form sparks as well as the ultraviolet and infrared light which is cast during the welding process. An auto tinting welding helmet blends the best in protection with the ease of hands-free use. Auto tinting helmets use a photosensitive filter to “tint” the viewing area to a pre-set shade automatically before the light hits the user’s eye. When the weld is completed the viewing area “un-tints”, allowing the user to see his results without lifting the mask. Using a high-quality auto tinting helmet increases the detection time, thus protecting the user better. What makes a high-quality helmet?
  • CSA or UL approval is a must for any helmet to be considered for use.
  • The detection time (tinting speed) must be at least 1/20,000 of a second to ensure the eyes are protected properly.
  • Multiple photo sensitive sensors increase the efficiency of the helmet and provides better protection.
  • Multiple shade settings so the same helmet can be used for all welding processes in a variety of light conditions.
  • Large viewing area for ease of use in confined areas.
  • Light weight design to reduce neck fatigue during prolonged use.
  • Batteries which can be easily changed and are commonly available.

Available models :

Superior True-View Black
Superior True-View Black

Part Number : CWPOWER-990T-BLK
MSRP Price : $178.00

Add to Cart

Superior True-View Blue Flame
Superior True-View Blue Flame

Part Number : CWPOWER-990T-BL
Superior True-View Coal Fire
Superior True-View Coal Fire

Part Number : CWPOWER-990T-CO
Superior True-View Sugar Maple
Superior True-View Sugar Maple

Part Number : CWPOWER-990T-SM

Description

  • View: True Color Lens
  • Cartridge Size: 115x133x10 mm
  • Viewing Area: 100 X 98 mm
  • Shade Adjustment: External, Variable shade 5 ~ 8 / 9 ~ 13
  • Power On/Off: Fully Automatic
  • Sensitivity Control: External, Infinitely adjustable from low to high
  • UV/IR Protection: Up to Shade DIN16 at all times
  • Power Supply: Solar Cell + 1 CR2450 Replaceable Lithium Batteries
  • Detection Time (LSAS): lesser than 1/20,000 S, From Light to Dark
  • Dark to Light Delay: External, 0.1-1.0 S Infinitely adjustable from low to high
  • Arc Sensor: 4
  • Light State: DIN 4
  • Low Amperage TIG: ≥5 Amps (DC), ≥5 Amps (AC)
  • Grinding Function: Yes
  • Low Volume Alarm: Yes
  • Optical Clarity: 1/1/1/1
  • ADF Self-Check Yes
  • Operating Temp: -5°C to +55°C
  • Storing Temp: -20°C to +70°C
  • Weight: 1.42 Lb. (645 g.)
  • Standards: ANSI/ISEA Z87.1-2015

Additional information

Weight 4 lbs
Dimensions 9.5 × 9.5 × 13 in
